YGBK-100-1 Dry Ice Pelletizer

 Tip: click the picture to enlarge.

The Magicball Dry Ice Pelletizer YGBK-100-1 is a compact, powerful and versatile machine producing high quality dry ice pellets in the sizes 3mm, 6mm, 10mm, 16mm and 19mm (1/8, 1/4, 3/8, 5/8 ,19/25 in) for a medium-sized dry ice requirement. This dry ice machine production capacity is 100-120kg/h (220-260 lbs/h) in the daily working process. ( Download PDF )



Dry Ice Pelletizer YGBK-100-1


Motor Power(kw)

5.5

Liquid inlet pressurempa

2.1

Dry Ice Size (mm)

3-19

Liquid inlet diameter(mm)

DN10

Dry Ice Size(inch)

0.1-0.7

Exhaust pipe diameter  (mm)

DN50

Min-Max  (kg/h)

100-120

Fuel tankage  (l)

200

Raw Materials(t/m³)

1.5

Overall Dimension(cm)

160*140*170

CO²Transformation rate

38%

Weight(kg/lbs)

750/1650




YGBK-100-1 Production Video, The same as YGBK-50-1 dry ice pelletizer machine.






Feature:

★ OMRON PLC and touch screen enable automation and digital production;

★ The stainless steel housing resists long-term corrosion of the condensate;

★ Adopt low noise digital servo control system;

★ Advanced technology makes dry ice conversion rate higher than 38%;

★ The use of cold gas from the exhaust gas to cool the oil temperature greatly reduces energy consumption;



Application:

For low temperature cleaning
For viticulture applications: vat inertia, protected harvest, vat homogenization, mixing, carbonization...
For the agri-food industry: meat processing industry, industrial biscuits...
Road transport: temperature control, medical, veterinary and food transportation.
For entertainment: dry ice fog effect.


Dry Ice Pellet Size:








              3mm (1/8 in )                       9mm (3/8 in)                        16mm(5/8 in )

             Dry Ice Blasting                  Cooling Purposes                   Cooling Purposes









BENEFITS OF DRY ICE PELLETIZER MACHINE:

1. Phase industrial voltage: For global installation

2. Fully automated: Start up & Shut down

3. Dry ice pelletizer mold:3mm,9mm,16mm,19mm

4. High transformation rate: LCO2:dry ice=2.3-2.5 Ton:1 Ton

5. Surface & Mold: 304 Stainless Steel

6. Production Time: Recommend 8-10 hours/day, acceptable 24 hours during peak season.

7. Hydraulic nsystem---Taiwan Brand        PLC---OMRON Brand

     Intermediate relays---OMRON Brand    Solenoid valve---DANFOSS Brand




We support our customers building up their dry ice business and are pleased to also provide our advice in regards to dry ice blasting machine and dry ice storage container.
